Cámara
- Sensor de imagen: 1/2.7″ Progressive Scan CMOS
- Max. resolución: 1920 × 1080
- Iluminación mínima: Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
- Tiempo de obturación: 1/3 s to 1/100, 000 s
- Día y noche: IR cut filter
- Ajuste de ángulo: Pan: 0° to 355°, tilt: 0° to 75°
Lente
- Focal Length & FOV 2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2°
- 4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
- Montura del lente: M12
- Enfoque: Fixed
- Apertura: F2.0
Iluminador
- Tipo de luz suplementaria: IR
- Rango de luz suplementaria: Up to 30 m
- IR wavelength: 850 nm
Vídeo
- Main stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 720)60 Hz: 30 fps (1920 × 1080, 1280 × 720)
- Sub-stream: 50 Hz: 25 fps (640 × 480, 640 × 360)60 Hz: 30 fps (640 × 480, 640 × 360)
- Compresión de video: Main Stream: H.265/H.264/H.264+/H.265+Sub-Stream: H.265/H.264/MJPEG
- Vídeo bitrate: 32 Kbps to 8 Mbps
- Tipo H.264: Baseline Profile/Main Profile/High Profile
- Tipo H.265: Main Profile
- Región de interés (ROI): 1 fixed region for main stream
Red
- Protocolos: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
- Vista en vivo simultánea: Up to 6 channels
- API: Open Network Video Interface, ISAPI
- Usuario/Operador: Up to 32 users. 3 levels: administrator, operator and user
- Cliente: iVMS-4200, Hik-Connect
- Navegador web: Plug-in required live view: IE 10+Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
Imagen
- Configuración de imagen: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
- Interruptor día/noche: Day, Night, Auto, Schedule
- Wide dynamic range (WDR): Digital WDR
- Mejora de la imagen: BLC, 3D DNR
Interfaz
- Ethernet interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
Evento
- Evento básico: Motion detection, video tampering alarm, exception
- Linkage: Upload to FTP, notify surveillance center, send email
General
- Alimentación: 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plugPoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
- Material: Metal & Plastic
- Dimensión: Ø110 mm × 82.4 mm (Ø4.4″ × 3.2″)
- Dimensión del paquete: 134 mm × 134 mm × 108 mm (5.3″ × 5.3″ × 4.3″)
- Peso: 410 g (0.9 lb.)
- Condiciones de almacenaje: -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
- Condiciones de inicio y funcionamiento: -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
- Idioma: English, Ukrainian
- Función general: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Certificaciones
- EMCFCC (47 CFR Part 15, Subpart B)CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)
RCM (AS/NZS CISPR 32: 2015)
IC (ICES-003: Issue 7)
KC (KN32: 2015, KN35: 2015)
- Seguridad: UL (UL 62368-1)CB (IEC 62368-1: 2014+A11)
CE-LVD (EN 62368-1: 2014/A11: 2017)
BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005)
- Ambiente: CE-RoHS (2011/65/EU)WEEE (2012/19/EU)
Reach (Regulation (EC) No 1907/2006)
- Protección: IP67 (IEC 60529-2013)IK10 (IEC 62262:2002)
